HOSE FITTING ASSEMBLY
REF.NO
REF.NO
REF.NO
REF.NO PART.NO
PART.NOPART.NO
PART.NO DESCRIPTION
DESCRIPTIONDESCRIPTION
DESCRIPTION QTY
QTYQTY
QTY I.C
I.CI.C
I.C REMARK
REMARKREMARK
REMARK
1 1012S-M0803-35 SEM'S BOLT, M8-1.25P 35L 4
2 227102 BUCKET CYLINDER ASSEMBLY 1
3 227101 DIPPERSTICK CYLINDER ASSEMBLY 1
4 227103 BOOM CYLINDER ASSEMBLY 1
5 225806 SWING CYLINDER ASSEMBLY 2
6 224304 STABILIZER CYLINDER ASSEMBLY-LH 1
7 224305 STABILIZER CYLINDER ASSEMBLY-RH 1
8 6003-0204 ADAPTER LONG, 1/2-20UNFx3/4-16UNF, O-RING 4
9 6003-0205 ORIFICE LONG, 1/2-20UNFx3/4-16UNF, O-RING 2
10 6003-0203 ADAPTER SHORT, 1/2-20UNFx3/4-16UNF, O-RING 4
11 6003-0206 ORIFICE SHORT,1/2-20UNFx3/4-16UNF, O-RING 2
12 6003-0302 ADAPTER ELBOW, 3/4-16UNFx7/8-14UNF, O-RING 90˚ 2
13 6003-0408 NIPPLE, PT1/2x3/4-16UNF 2
14 8044K-01100 DUST CAP, 1/2, BLACK 2
15 80410-T1130 QUICK COUPLER, PT1/2 MALE 2
NIPPLE, PF1/4, O-RING x1/2-20UNF
- 43 -
16
6004-0205 NIPPLE, PF1/4, O-RING x1/2-20UNF 16
17 802N1-F67F7-50 NIPPLE, 9/16-18UNFx1/2-20UNF 2
18 5004-0034 O-RING, AS568 #908 12
19 5004-0014 O-RING, P11 16
20 5004-0078 O-RING, AS568 #910 2
21 BT664-83100 NIPPLE KIT, 1/2-20UNFx1/2-20UNF, NUT 2
22 BT665-82140 PIPE ASS'Y 1
23 BT664-82150 PIPE ASS'Y 1
24 802N1-P26F7-52 ADAPTER, PF1/4x9/16-18UNF 2
25 BH30-0100 HOSE ASS'Y (SWING TO SWING), 1/4x4x4x550L 2
26 BH30-0200 HOSE ASS'Y (SWING TO VALVE), 1/4x904x4x950L 2
27 BH30-0300 HOSE ASS'Y (STABILIZER), 1/4x904x4x1300L 4
28 BT665-83120 HOSE ASS'Y (VALVE TO FIXED), 1/4x904x4x2700L 2
29 BT665-83130 HOSE ASS'Y (VALVE TO DIPPER. CYL), 1/4x904x4x2900L, 2
30 BT664-83140 HOSE ASS'Y (FIXED TO BUCKET CYL), 1/4x4x4G/Wx900L 2
31 BT664-83150 HOSE ASS'Y (VALVE TO BOOM CYL), 1/4x904x4x1850L 2
32 BT664-83160-01 HOSE ASS'Y (VALVE TO IN OUT), 1/2x4x4x1900L 2
33 8001-B010 BAND, 10 3
34 COM02-11101 FIX, PIPE 2
35 802L0-T63FA-32 NIPPLE , PT1/2x7/8-14UNF, O-RING 90˚ 1
36 801K1-13000 CHECK VALVE, PT1/2-0.5K 1
37 802N3-T63FA-30 NIPPLE , PT1/2x7/8-14UNF, HOSE 1
- 43 -
