CONTROL VALVE ASSEMBLY-HANIL AV 80/6
REF.NO
REF.NO
REF.NO
REF.NO PART.NO
PART.NOPART.NO
PART.NO DESCRIPTION
DESCRIPTIONDESCRIPTION
DESCRIPTION QTY
QTYQTY
QTY I.C
I.CI.C
I.C REMARK
REMARKREMARK
REMARK
0 BC04-0000-P Control Valve Ass'y 1
1 BC04-0100 BLOCK ; BA TYPE(INLET) 1
2 BC04-0200 BLOCK ; HB TYPE(BOOM) 1
3 BC04-0300 BLOCK ; HA TYPE 2
4 BC04-0400 BLOCK ; EA TYPE 3
5 BC04-0500 BLOCK ; GB TYPE (OUTLET) 1
6 BC04-0600 O-RING 7
7 BC04-0700 PLUG ASS'Y 1
8 BC04-0800 POPPET ; CHECK 6
9 BC04-0900 SPRING ; CHECK 6
10 BC04-1000 PLUG-CHECK ASS'Y 6
11 BC04-1100 M.R.V. ASS'Y 1
12 BC04-1200 O.R.V. ASS'Y 4
13 BC04-1300 A.C.V. ASS'Y 2
14 BC04-1400 SPOOL ASS'Y ; FLOAT 1
15 BC04-1500 SPOOL ASS'Y ; STD 3
16 BC04-1600 SPOOL ASS'Y ; STABILIZER 2
17 BC04-1700 RETURN CAP 6
18 BC04-1800 WRENCH BOLT 18
19 BC04-1900 HOUSING ; DETENT 1
20 BC04-2000 SOCKET ; DETENT 1
21 BC04-2100 BALL ; DETENT 4
- 51 -
23 BC04-2300 SPRING ; RETURN 1
24
BC04-2400 WRENCH BOLT 2
25 BC04-2500 O-RING 1
26 BC04-2600 SEAL KIT ASS'Y ; FLOAT 1
27 BC04-2700 O-RING 5
28 BC04-2800 DUST WIPER 5
29 BC04-2900 SEAL PLATE 3
30 BC04-3000 BRACKET ; STABILIZER 2
31 BC04-3100 WRENCH BOLT 6
32 BC04-3200 BRACKET ; JOINT 2
33 BC04-3300 SUPPORT ; JOINT 2
BC04-3400 BLOCK ; JOINT 2
35 BC04-3500 SUPPORT ; BALL 6
36 BC04-3600 NYLON NUT 6
37 BC04-3700 LEVER ; STABILIZER 2
38 BC04-3800 PIN 4
39 BC04-3900 WASHER ; PIN 4
40 BC04-4000 SNAP PIN 4
41 BC04-4100 SPRING PIN 4
42 BC04-4200 NUT 8
43 BC04-4300 TIE BOLT 4
44 BC04-4400 BOOT , CONTROL 2
45 BC04-4500 HAND LEVER 2
46 BC04-4600 BOOT , CONTROL 2
47 BC04-4700 HAND LEVER 2
48 BC01-2400 PLASTIC BALL 2
49 BC04-4900 LEVER STICK 2
50 1002-1051 NUT 4
51 BC04-5100 PLASTIC BALL 2
52 BC04-5200 LEVER STICK 2
- 51 -
