E
MAINTENANCE
E
5
When working in a grassy field or
working at night, the radiator or
condenser grille may be clogged by
grass, straws or bugs, reducing cooling
performance.
Clean the grill in this case. If dust is
stuck between the fin and tube, flush
the area with clean water.
▶ CLEANING RADIATOR GRILL
AND CONDENSER GRILL
Turn the opening lever to access to the
condenser and oil cooler.
Clean them with clean water.
Remove the grill by unscrewing the pin
(1) and moving it in the arrow direction.
(1) Inspection
1. Pull out the dipstick, wipe its tip
and insert it again. Then, pull it out
and check that the oil level is
between the upper and lower limits.
2. If the level is below the lower limit,
add oil.
▶ CLEANING CONDENSER GRILL
AND OIL COOLER
▶ CHECKING AND CHANGING
ENGINE OIL
Do not clean the radiator fin with water
jet. It can deform the fin.
IMPORTANT
(1)
RADIATOR
SCREEN
OPENING LEVER
OIL FILLING HOLE
ENGINE OIL DIPSTICK
