E
MAINTENANCE
E
13
(3) Tighten the drain valve
1. Tighten the drain valve (A) at the
bottom of the fuel filter.
Drain water and remove foreign
materials from the fuel filter at every
100 hours of operation.
1. Remove the plug (1) on the bottom
of the filter. It can be removed by
unscrewing it.
2. Drain water and remove foreign
materials completely. Then, fit the
plug.
3. Then, run the engine to bleed the
system.
1. Open the drain plug (1) to drain fuel
in the filter.
2. Unscrew the filter (2) from the filter
head.
3. Push and turn the element in the
filter counterclockwise to remove it
from the filter body.
4. Screw in a new O-ring and element
into the filter body.
5. Turn the filter until the filter body
touches the filter head.
▶ CLEANING FUEL FILTER
▶ REPLACING FUEL FILTER
ELEMENT
Do not use tools to loosen the drain
valve.
Use of tools may damage the drain valve.
CAUTION
(2)
(1)
