TRACTOR INSTRUMENTS
C
21
< Power shift button>
The transmission can be shifted to the
high speed or low speed gear with the
power shift button pressed even when
the clutch pedal is released.
• Button 1: High speed
• Button 2: Low speed
(7) Range shift lever
Shifting operation can be performed in
combination with the shuttle shift lever,
main shift lever and range shift lever.
Speed Range:
• 32 forward driving speeds and
• 32 reverse driving speeds
Do not drive backward with the range
shift lever placed in the H position as
driving backward with fast speed can
lead to a dangerous situation
WARNING
To operate the range shift lever, depress
the clutch pedal and wait till the tractor
is completely stopped.
If operating the lever during driving, it
can damage the gears.
The main shift lever can be moved as
long as the clutch pedal is fully
depressed during driving as it is a
synchromesh type.
When shifting the range shift lever to the
H position or the main shift lever to the
3
rd
or 4
th
gear position during starting
off or with the driving speed of 3.8 km/h
or slower, the warning buzzer sounds
and the shuttle shift operation is
disabled.
IMPORTANT
Cautions for position C of range shift
lever
When the range shift lever is in the
position C, rotating force of the axle acts
greatly. Therefore, misuse can lead to
damage of gears and other parts. Be
careful with the followings:
Types of work appropriate for creep
speed gear
- Cultivating deeply at short intervals
with rotavator
- Cultivating with rotavator, but hard to
work at standard speed due to firm
ground
- Transplanting
- Loading/Unloading
- Working with trencher
Types of work inappropriate for creep
speed gear
- Escaping from wet field
- Draft (trailer) work
-Working with front loader
- Construction work
-Working with front snow plow
IMPORTANT
