C
TRACTOR INSTRUMENTS
32
< Differential lock >
The differential lock is designed to lock
the differential system in order to rotate
the left and right wheels at the same
speed. Use this device when the rear
wheels slip or one wheel spins with no
traction.
1. Manual mode
It is possible to control the differential
manually by a driver for easier
operation.
Pressing the button once turns on the
lamp and activates the manual mode.
Pressing it once again turns off the lamp
and deactivates the manual mode.
• Examples of useful conditions of
differential lock
1. One wheel slips or tractor cannot be
driven forward when moving
into/out of a field.
2. A wheel slips during work requiring
traction, such as plowing.
3. One wheel is stuck into a soft field
and can't escape.
< 4WD >
The 4WD function can be operated in
any gear during driving (forward/
reverse driving).
1. Automatic mode
The 4WD function is automatically
deactivated when the angle of one
of the front wheels is over 20
degrees or the vehicle speed
exceeds 15 km/h.
Pressing the button once turns on
the lamp and activates the
automatic mode. Pressing it once
again turns off the lamp and
deactivates the automatic mode.
Never use the differential lock when
driving on a road. A collision or rollover
can occur.
Make sure to deactivate the function
before turning. Otherwise, it can lead to
an injury or accident.
CAUTION
When using the differential lock, run the
engine at a low speed.
The differential lock is disengaged when
depressing the brake pedal.
The differential lock is disengaged when
the vehicle speed exceeds 15km/h.
IMPORTANT
MANUAL DIFFERENTIAL LOCK MODE AUTOMATIC 4WD MANUAL 4WD
