C
TRACTOR INSTRUMENTS
36
1. The angle of an implement can be
adjusted by extending or retracting
the top link.
2. After adjustment, fix the adjusting
handle so that the link does not
become loose.
3. The mounting location of the top
link is different by the type of an
implement. The 1st and 2
nd
holes
from the top are generally used.
▶ TOP LINK ADJUSTMENT
Turn the handle clockwise to extend the
rod and turn it counterclockwise to
retract the rod.
Adjust the length of the lift rod to keep
the implement in balance.
1. To adjust the height, lift the
adjusting handle. After adjustment,
lower the handle and fix it.
2. Adjust the length according to the
type of an implement.
• C: for rotary tiller and other types of
implements
• D: for rotary tiller
▶ LIFT ROD ADJUSTMENT
▶ LOWER LINK CONNECTING HOLE
TOP LINK FIXING BAR AND
ADJUSTING HANDLE
LIFT ROD ADJUSTING HANDLE
LOWER LINK
CONNECTING HOLE
D
C
