TRACTOR INSTRUMENTS
C
37
The adjusting link can be adjusted to
relieve vibration and shock.
▶ ADJUSTING LINK
An implement can be attached to this.
The installation type is Category Il.
(Implement mounting hole diameter:
25.4 ㎜)
Install only an implement applicable to
this tractor.
▶ LOWER LINK
▶ TOWING HITCH
When no implement is attached, fix the
lower links with the left and right check
links so that they do not touch the rear
wheels.
Engage the top link with the hook.
IMPORTANT
Make sure to use the towing hitch for
towing to avoid rollover. Never tow
anything by connecting a rope to the
top link bracket, axle or safety frame.
When using a rotavator that draws
power through the universal joint from
the PTO shaft, remove the towing hitch
from the tractor. Otherwise, the
universal joint hits and damages the
towing hitch, leading to an accident.
WARNING
ADJUSTING HANDLE
LIFT ROD MOUNTING HOLE
TOWING HITCH
