C
TRACTOR INSTRUMENTS
48
There are two circulation modes for the
A/C and heater operation:
fresh air mode and recirculation mode.
<Fresh air/recirculation mode
selection>
The fresh air mode or recirculation
mode can be selected by opening or
closing four vents on the roof in the
cabin.
• Open - Recirculation mode
• Closed - Fresh air mode
1. Seat sliding
The seat position can be slid
forward or backward with the lever
in front of it pushed to the left.
After adjustment, make sure that
the seat is firmly secured.
2. Seat cushion adjustment
urn the lever on the front of the seat
to adjust the cushion properly
according to the driver's weight.
3. Seatback reclining
The angle of the seatback can be
adjusted by pulling up the angle
control lever.
▶ FRESH AIR MODE AND
RECIRCULATION MODE
▶ DRIVER’S SEAT
If the cabin needs to be ventilated,
select the fresh air mode.
Then, fresh air is drawn into the cabin
from outside through the filter.
The air suction filter can be clogged by
dirt and foreign materials during work.
Clean it periodically and replace it when
necessary.
WARNING
The fresh air suction filter can remove
dust in air, but not chemicals in
pesticides.
Misuse of such chemicals can harm
driver and others' health.
Make sure to follow dust inhalation
safety instruction, personal hygiene
guidance and other precautions from
the manufacturers of the tractor and
chemicals.
IMPORTANT
(5)
(4)
(3)
(2)
(1)
