TYPHOON Q500 - Page 20

Flashes red and green slowly (2 mes per second)
Flashes red and green rapidly (5 mes per second)
Flashes red, green and blue rapidly
(3 mes per second)
Flashes red, green and blue slowly
(1 me per second)
Glows solid white
Glows solid red
Flashes yellow (1 me per second)
Glows solid green
Glows solid blue (1 me for 2 seconds)
Flashes green, blue slowly (1 me per 2 seconds)
LED STATUS INDICATIONS FOR CALIBRATION MODES
Main LED Status Indicator
Compass calibraon Mode entered
Compass calibraon started
Accelerometer calibraon started
Accelerometer calibraon Mode entered/data collecon
finished
Calibraon failed
CGO2-GB CAMERA LED STATUS INDICATIONS
WiFi / camera inializaon in progress
MicroSD card error or missing microSD card
Ready
Taking sll photo
Recording video
1 second 1 second 1 second
18
When the Flight Mode Selecon Switch is in the boom posion the Q500
will be in Home (also known as Return to Home) Mode.
Flashes red, green and blue connuously
Flashes purple (1 flash per second)
Second level low voltage baery warning
GPS lost
Compass calibraon required
Below Motor LED Status Indicators
Low voltage baery warning
GPS disabled/lost
Flashes orange twice between any LED indicaon
(when in the air)
Flash rapidly (5 mes per second)
Flash 3 mes per second then off 1 second second
