TYPHOON Q500 - St10 and Receiver Binding

ST10 AND RECEIVER BINDING
Step 1) Turn on the Q500, and aer
the Main LED Status Indicator begins
to flash blue rapidly, li the back end
upward approximately 45° then back
down to ‘level’ two (2) mes to put
the aircra/receiver into bind mode.
The Main LED Status Indicator will
begin to the flash orange very rapidly
when the aircra/receiver are in bind
mode.
2 x 45+°
Step 2) Turn on the ST10,
and if required tap the
screen (outside of the pop
up status window) to
bypass the RC and WiFi
connecon process.
Step 3) Tap the ‘Model
Select’ buon, and if
required press ‘OK’ to
bypass any pop up
warnings/alerts.
Step 4) Select the exisng
model (for example:
‘Q500’) you would like to
bind to (or create a ‘New
Model’), and if required
press ‘OK’ to bypass any
pop up warnings/alerts.
Step 5) Tap the ‘Flight
Sengs’ buon, and if
required press ‘OK’ to
bypass any pop up
warnings/alerts.
Step 6) Tap the ‘Bind’
buon and select the
‘SR12S_XXXXX’ receiver
listed in the column under
‘Model’, then tap ‘OK’ aer
the connecon has been
established.
Step 7) Tap the ‘Back’
buon two (2) mes to
return to the main screen
and the model/receiver
should automacally
connect to the ST10.
