1
2
3
4
5
6
7
8
PUSH
I
1
-7-
12
13
2
2
1
2
3
4
5
6
7
8
PUSH
I
3
1
2
14. Adjusting the stitch length (Fig.12)
While press the stopper ②, turn the stitch length
dial ① to make the number on the dial align with
the mark on the stopper ②. The number is the
stitch length in mm.
＊The larger the number, the longer the stitch
length will be.
＊When turn the dial from a larger setting to a
smaller setting, it will be easy to turn if the
reverse lever ③ is pressed down.
15. Sewing and backtacking (Fig.13)
1.Turn the power on;
2.Depress the treadle to start sewing.
When the reverse lever ① is pressed or the
backtacking button is on during sewing, the feed
will be reversed. After release, the feed will
recover to normal.
