typical GC6-7 - Page 9

K
11
6
Oil Hole A up to PartF. G. H. I. J(See Fig9).
Oil Hole B up to PartC. D. E(See Fig10)through
9 oil wick.
10
D
E
B
C
A
I
G
F
H
J
9
The bevel gear cases in Fig. 11 and Fig.12 are
packed with grease, which should be replenished
periodically as may be consumed gradually after
long time of operation . When replenish, turn off
screw plugs L,K first and packed with fresh grease
thru screw hole into gear cases then screw on screw
plugs. Should the grease in the bevel gear cases
been too dirty or partial hardened, it must be
changed thoroughly
