To utilize the optional TH-9000D software, you must first connect the transceiver to your

Microphone [THM-03] Antenna [TCA-01]

Microphone connector

External speaker [SP-01]

DATA

PWR

TH-9000

SP-01

Error

Ground

Microphone

For voice communications, connect a microphone equipped with an 8-pin modular plug

into the modular socket on the front of the main unit. Press firmyly on the plug until the

locking tab clicks. Attach the supplied microphone hanger in an appropriate location using

the screws included in the screw set.

PC Connecting

PC then using an optional programming cable PC50 (via Data socket ).

Please use TH-9000D software for programming.

NOTE: Ask your dealer about purchasing a Programming Cable PC50.
