Front panel
Getting Acquainted
Basic Functions
14
3 11 4 5 6 1
7 8 9
2
12 10
Pow(Power)
VOL
Main Dial
F
P1
P2
P3
P4
P5
Data Terminal
TX
Mic.connector
Power on/Off
Adjust Volume Key
Change frequency, memory channel and scan direction etc.
Function Key
Call key
Squelch off
Switch VFO/MR mode
Step key (step: 1MHZ)
Set CTCSS/DCS
Data reading/writing, cloning and theft alarm functions
lights during Transmitting
Microphone connection port
1
2
3
4
5
6
7
8
9
10
11
12
NO. KEY FUNCTION
15
Press key and following key together to activate following function:
Press key until icon appears then press the following key.
Functions that require continuous pressing following key to be activated
FUN/SET
Press and hold for 2s to enter the Setting mode4
NO. KEY FUNCTION
Note:P1-P5 keys setting above are default. Users can modify then according to their need
by program software.
F
P1
P2
P3
P4
Confirms the selective functions and exit
Voice compander
Store memory channel
Delete memory channal
Keypad lock
4
5
6
7
8
NO. KEY FUNCTION
P1
P2
P3
P4
P5
Data clone
Power voltage display
Scan mode
Repeater offset set
Auto dialer setting
5
6
7
8
9
NO. KEY FUNCTION
