41
COMBO 75FF (2 of 2)
Previous Design Starting With Serial Numbers
7CF300000, 7CF400000 or 7CF500000
Item Description Part No.
1 Water Line 404FF
2 Water Line Connection 41826
3 Plastic Nut & Sleeve Ass’y 41254
7 Cabinet Foot (4) 41319
8 Dryer 2692
10 Fan Motor, Condenser 5263
11 Fan Blade, Condenser 5188
12 Condenser 1951-FFS
13 Back Panel 11769
Item Description Part No.
16 Power Cord 2242
17 Solenoid Valve 2552A
18 *Compressor 5405-FFS
19 ***Relay/Overload 5421
21 Bypass Valve Ass’y 2749-S
24 Drain Pan 31550-1-F
25 **Capacitor 5422
26 **Insulation 31612
* Replaces P/N 5402-FFS through installation of kit.
** New part added through installation of kit.
*** Replaces P/N's 5413 & 5414 through installation of kit.
To Next Page
