U-Line CLR2060 User Manual

14
User’s Manual
UL314
CHECK
LEVEL
Figure 8
UL205A
T
URN FOOT TO ADJUST
Figure 9
LEVELING THE UNIT
NOTE
It is extremely important that the unit is level. If it is not
level, the ice mold will not fill evenly. This can cause a reduc-
tion in ice rate, uneven sized cubes or water spilling into the
storage area which will cause the ice in the bin to melt pre-
maturely. Remember that floors near drains have a ten-
dency to slope towards the drain.
1. Use a level to check the levelness of the ice maker from front to
back and from side to side (see Figure 8).
2. If the ice maker is not level, adjust the feet on the corners of the
unit as necessary (see Figure 9).
3. Check the levelness after each adjustment and repeat the previous
steps until the unit is level.
Body_UM.qxd 12/17/04 9:16 AM Page 14
