22
User’s Manual
BUILT-IN INSTALLATION
Your U-Line product has been designed for either free-standing or built-
in installation. When built-in, your U-Line product does not require addi-
tional air space for top, sides or rear. However, the front grille must
NOT be obstructed.
Do not install unit behind closed doors.
Table 3. Built-in Cabinet Dimensions
Model
Unit Dimensions
Width Height Depth
CLR2060 14-15/16" 34-1/8" 24"
NOTE
Required for ease of installation, removal and door opening,
you must allow an additional 1/4" to width of unit. The unit
must be located to allow clearance for water, drain and
electrical connections in the rear of the ice maker.
CAUTION
H
D
W
UL118
Figure 25
Body_UM.qxd 12/17/04 9:16 AM Page 22
