PAGE 2 OF 27 0417 IH-1649
Unit Key (UNIT) – Selects weighing units: pounds,
ounces, kilograms, grams.
Accumulate Key (ACC) – Adds a value to the
accumulated total if the accumulation function
is not automatic.
Escape Key (ESC) – Used to return the scale to
normal operating mode.
Function Key (FUNC) – Allows switching from parts
weighing to parts counting.
Clear Key (C) – Used to reset parameters or other
functions.
Percent Key (%) – Enters the percent weighing
function. Allows weight, unit weight and count to
show when counting parts.
Space Left (<) – Used to change different numbers
on the display. Also used to set parameters or other
functions.
Limit Key (LIMIT) – Sets limits for check weighing.
Set high or low limit or both.
Space Right (>) – Used to change different
numbers on the display. Also used to set
parameters or other functions.
Tare Key (TARE) – Deducts the container weight
from pieces' weight.
Number Key (^) – Used to set parameters and
other functions.
Zero Key (ZERO) – Zeros display for next weight.
ENTER Key – Used to set parameters and other
functions.
MODEL # H-1653/H-1654 H-1649 H-1650 H-1651
MAXIMUM CAPACITY
3kg / 6 lbs. 6kg / 12 lbs. 15kg / 30 lbs. 30kg / 60 lbs.
MINIMUM CAPACITY 2g 4g 10g 20g
ACCURACY (DIV) 0.1g /.0002 lbs. 0.2g /.0005 lbs. 0.5g /.001 lbs. 1g /.002 lbs.
RESOLUTION 1:30.000
TARE RANGE -3kg -6kg -10kg -30kg
REPEATABILITY (STD DEV) 0.1g 0.2g 0.5g 1g
LINEARITY ± 0.2g 0.4g 1g 2g
UNITS OF MEASURE kg, g, lbs., oz
STABILIZATION TIME 2 Seconds
OPERATING TEMPERATURE 0˚C - 40˚C / 32˚F - 104˚F
POWER SUPPLY (EXTERNAL) 115/230 Vac, 50/60Hz, 10 watts
CALIBRATION Automatic external
DISPLAY 6 digits LCD digital display
BALANCE HOUSING ABS plastic, stainless steel platform
PAN SIZE 225 x 300 mm / 9 x 11.5"
OVERALL DIMENSIONS (WxDxH) 320 x 340 x 125 mm / 12.6 x 13.4 x 4.9"
NET WEIGHT 3.8kg/8.4lb
APPLICATIONS General purpose scale
FUNCTIONS Weighing, parts counting, % weight, check weighing
OTHER FEATURES AND SPECS Internal rechargeable battery (~70 hours operation)
SPECIFICATIONS
CONTROLS
Primary Function Secondary Function
Unit
Acc
Func
%
ESC
C
Limit
Tare
Zero
