uAvionix SkyEcho 2 - Table of Contents

UAV-1002156-001
ECCN 7A994 Page 6 | 31
4 Contents
1 Revision History ................................................................................... 3
2 Warnings / Disclaimers ........................................................................ 4
3 Limited Warranty .................................................................................. 5
5 Introduction .......................................................................................... 8
5.1 Features........................................................................................ 9
5.2 Regulatory Compliance ............................................................... 10
5.2.1 CAA CAP 1391 Declaration ................................................... 10
6 Specifications .................................................................................... 12
7 Limitations ......................................................................................... 13
7.1 Installation ................................................................................... 13
8 Equipment Installation and Configuration ........................................... 16
8.1 Mounting ..................................................................................... 16
8.2 Connections ................................................................................ 17
8.3 Installation Setup ........................................................................ 17
8.3.1 Connecting to the SkyEcho2 via Wi-Fi ................................... 17
8.3.2 1090ES Transmit ................................................................... 20
8.3.3 Receiver Mode ...................................................................... 20
8.3.4 Region ................................................................................... 20
8.3.5 Aircraft Address Programming (ICAO Address) ..................... 20
8.3.6 Call Sign ................................................................................ 21
8.3.7 Emitter Category ................................................................... 21
8.3.8 VFR Squawk ......................................................................... 23
8.3.9 ADS-B IN Capability .............................................................. 23
8.3.10 Air/Ground Threshold Speed VSO (knots) .......................... 23
8.3.11 Aircraft Length and Width in Meters .................................... 23
8.3.12 GPS Antenna Offsets ......................................................... 24
