SARA-R5 series - System integration manual
UBX-19041356 - R04 Approvals Page 109 of 118
C1-Public
⚠ Radiofrequency radiation exposure Information: this equipment complies with radiation exposure
limits prescribed for an uncontrolled environment for fixed and mobile use conditions. This
equipment should be installed and operated with a minimum distance of 20 cm between the
radiator and the body of the user or nearby persons. This transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter except as authorized in the
certification of the product.
⚠ The gain of the system antenna(s) used for SARA-R5 series modules (i.e. combined transmission
line, connector, cable losses and radiating element gain) must not exceed the values stated in the
Declaration of Conformity of the modules, for mobile and fixed or mobile operating configurations:
o 7.4 dBi in 700 MHz, i.e. LTE FDD-28 band
o 8.2 dBi in 800 MHz, i.e. LTE FDD-20 band
o 8.4 dBi in 900 MHz, i.e. LTE FDD-8 band
o 11.3 dBi in 1800 MHz, i.e. LTE FDD-3 band
o 11.8 dBi in 2100 MHz, i.e. LTE FDD-1 band
The conformity assessment procedure for the SARA-R5 series modules, referred to in Article 17 and
detailed in Annex II of Directive 2014/53/EU, has been followed.
Thus, the following marking is included in the product:
4.5 GITEKI Japan
• SARA-R500S-00B, SARA-R510S-00B, SARA-R510M8S-00B
The gain of the system antenna used for SARA-R5 series modules must not exceed 3 dBi to comply
with Japan Technical Standard Conformity Certification (GITEKI Certification) requirements.
Additionally, the antenna used in the end-device system for SARA-R5 series modules has to be listed
on the technology conformity certified Antenna list of the related module. Please contact u-blox for
more information about how to add the antenna used in the end-device system into the Antenna list
of the related module.
