1.Key Parts
a. Slots:
c. Plugs:
Plugs on components come in dierent shapes and sizes, and are compatible with dierent fasteners.
b. Rudders: Rudders are rectangular structures projecting from components. The symbols "△□☆○" are used to indicate the
dierent directions.
Assembly Introduction
8
圆孔位
十字孔位
The slot is a groove in components, which usually appears on connectors and servos. When a component has multiple slots,
the "ABCDE" naming method will be used to distinguish them.
To Next Page
