Characteristics
Absolute Maximum Ratings
(†)
Supply Voltage................................................................................................................. 6V to 40V
Voltage on RX with respect to GND .............................................................................. -25V to +25V
Voltage on TX with respect to GND......................................................................... -13.2V to +13.2V
Ambient temperature under bias……………............................................................... -20°C to +85°C
Storage temperature.................................................................................................. -50°C to +150°C
†NOTICE: Stresses above those listed under “Absolute Maximum Ratings” may cause permanent damage to
the device. This is a stress rating only and functional operation of the device at those or any other conditions
above those indicated in the operation listings of this specification is not implied. Exposure to maximum rating
conditions for extended periods may affect device reliability.
Electrical Characteristics（Ambient Temperature 25℃）
Supply Power Voltage 6V ~ 40VDC
Current Consumption Max 100mA
Communication (Ambient Temperature 25℃）
To User Device RS232
Wiring Method DB9 Female Connector
RS232 Baud Rate MAX 115200 bps
To UIM242 Controller Active CAN 2.0B
CAN wiring Method 2-Wire,CANH,CANL
CAN bus
• Supports 1 Mb/s operation
• ISO-11898 standard physical layer requirements
• Suitable for 12V and 24V systems
• Up to 100 nodes can be connected
Environment Requirements
Cooling Free Air
Working
Environment Avoid dust, oil mist and corrosive gases
Temperature
-20 ℃ ~ + 85 ℃
Humidity
<80%RH，no condensation, no frosting
Vibration 3G Max
Storage Temperature
-50 ℃ ~ + 150 ℃
Size and Weight
Size 66.4mm x 38mm x 18mm (L*W*H)
Wight 0.1 kg
