8-6: « General Settings » menu
∇ Setting of LCD backlighting
(Depending on MiniSonic version)
∇ Filter rate of measurements
(Number of 0.5 s cycles)
∇ Last accepted measure (IQ > 33%)
Memorising time:
(Mode ESC: enter Mém. = > 20)
∇ Setting of Totalizers 1 & 2
> depending on flow direction:
∇ > depending on weight or unit:
(from 1 cl to 100 m3 )
∇ Setting of Relays 1 & 2
> By assignment:
∇ > If copy of TOT 1 or TOT 2:
= Relay closing time > F maxi
∇ > If Threshold: enter value for Q:
∇ Reset to Zero of TOT 1 & 2
This function may be prohibited
∇ Parameter settings of two outputs
[4-20 mA], SA 1 & SA 2
- By assignement:
- By range (depending on unit)
∇ RS 232 ou 485 Communication
Jbus slave No and Baud Rate:
Back Light
ON / OFF / TIMED
Mémory (s)= ∗∗
Threshold R2 (unit)
Value
Reset t1 & t2
NO / YES
+ , - , +/-
Closed/Open /TOT.1 ou 2 /
Fault Q/ Dir.Q/ Threshold Q
Pulse width ( ms )
N. JBUS = 1
BAUD = 9600
Filter = ∗∗
SA 1/ SA2 Type
Q , V , C , GAIN
4mA SA 1 & SA 2
+ / - xxxx.x
Pulse weight =
1 m3
20 mA SA 1 & SA 2
+ / - xxxx.x
