NT217 C GB1 15 / 27
7 - COMMISSIONING AND PARAMETERING OF MINISONIC 600 & 2000
1. Once the cabling has been carried out and verified, power up the system:
> The MiniSonic must display its home screens:
- Hardware version = MiniSonic 600 or 2000 or Ex d (2000)
- Firmware version = 18.10-01 (e.g. – make a note of the first figure)
- Serial number = see if it is identical to the company nameplate
- Technical information: parameterized probes
Then it automatically switches to the measurement function (Q = …)
> Check the consistency of these messages with respect to your application. If your
instrument is set ready to be used, you can start readings and records.
> However, it is recommended you to check and, if necessary, to optimize the
adjustments, taking into consideration the exact dimensions and, if possible, zero flow
conditions (see the “Self-zero Adjustment” menu).
2. Parameter settings using the PC software : Use same version than Firmware
> Refer to the manual supplied with the software (CD-ROM).
> The fields of the main values to be entered are listed below under Heading 8.
> The software offers extended configuration possibilities.
> At the end of the manual, a printout of a typical file is given.
3. Parameter settings using the keyboard
Successive pressing on the F key, or F then + or - gives access from the
“Measurements Display” menu to the titles of the different menus :
Access (Authorization) to Adjustments
Pipe parameters
Flow rate / Fluid parameters
Probe parameters
General parameters including Outlets
Zero adjustment
Tests
Optionally : “Current outputs setting” and “Factory Adjustments”.
To enter the Menu, use the ∇ key in the same way as to move to the next field to be
filled in .
To modify (text or values), use – or +
Exit from the menu is by the F key with return to the “Measurement Display” menu
If there is no action on the keypad for 1 mn, the MiniSonic automatically returns to
“Measurement Display” menu.
When inside a menu, the browser only scrolls forwards. When necessary, do a
complete scroll.
