Page #8 background imageLoading...
Page #8 background image
NT217 C GB1 8 / 27
2 - COMPOSITION OF A MEASUREMENT POINT
- The two probes
- The integrated or optional supports (SU * 2)
- The coupling kit if external clamp-on probes.
- Integral or optional supports (SU)
- Probe / converter link cables
- MiniSonic converter.
- PC / converter link cable and software (CD-ROM).
If requested in your P.O., external modules as an AC/AC. Transformer, AC/DC supply,
Zener barriers…
CERTIFICATIONS
All equipment is CE certified.
ATEX certification for the relevant probes and standards when this quality is required,
accepted and documented. All equipment will be labeled accordingly.
IP Rated as shown on each item.
The IP 67 rating of a MiniSonic is only complied with if assembly is according to
the manual and installations rules .
APPLICABLE STANDARDS:
Concerning high voltage human safety risks: N/A Only low voltage ( < 60 V ) .
Concerning EMC : EN 61000, EN 55022 et EN 50204
Concerning tightness ( IP ) : EN 60529
Concerning ATEX : Directive 94 / 4 / CE
+ EN 60079-0: General rules.
+ EN 60079-1 : Ex d enclosures.
+ EN 60079-7 : Ex e protection for connections.
+ EN 60079-18 : Ex mb x protection by encapsulation.
+ EN 60079-11 : Ex ia - Intrinsic safety
+ EN 60079-25 to guide you for your I.S. systems
Beware to take in account the energised lightings (from thunderstorms for instance)
and to place adapted modules when this risk can exist.
MINISONIC LIMITATIONS:
MiniSonic 600 is designed for pipes from 10 up to 630 mm O.D.
MiniSonic-2000 accepts applications on pipes up to 3300 mm O.D.
The maximum lengths between transducers ( L ) are 1250 mm for Mini-600 and 6600 mm
for Mini-2000 ( SM probes )
The maximum axial distances ( D ) are respectively 850 and 4400 mm .( SM probes )
The flow display format is limited to 999999.9 in each flow unit from l/h to m3/s.
