Page #25 background imageLoading...
Page #25 background image
NT217 C GB1 25 / 27
10 - INVESTIGATIONS
If there is a difficulty or a problem, logical analysis can be assisted by the
implementation of expert apparatus:
Either an oscilloscope: the MiniSonic has internally on its P.C. Board test points :
PT 0 = 0 Volt Ground
PT 1 = Selection windows. Echo must be inside.
PT 2 = Synchro Positive edge 0 to 5 Volt
PT 1 = Selection windows. Echo must be inside.
PT 3 = Emission < > Reception transit time.
PT 4 = Echo Alternating signal , peak to peak max = 4 Volt / 0.65 V negative
threshold.
Echoes display investigations can also be done by using a DigiSonic E / P portable
flowmeter
This device permits also ultrasonic thickness gauge option.
Or measuring instruments for dimensional or alignment measurements
SPARE PARTS:
Ultraflux offers possibilities of purchasing spare cards or, as long as acceptance is
granted, the standard replacement of equipment in the event of failure.
Contact the Ultraflux commercial services or the regional dealer.
