Unex SOM-352 Series User Manual

Doc. No: Unex-QSG-21-003
27/30
A printed version of this document is an uncontrolled copy
© 2023 Unex Technology Corporation – Company Confidential
Figure 11: SOM-352 dimensions
Table 12: Dimensions and weight
Model
Length (mm)
Width (mm)
Height (mm)
Weight (g)
SOM-352
51.0
38.5
11.5
21.2
10.1. Component Keep Out Area
Maximum height of bottom side components may reach 1.0mm. In order to avoid
interference with SOM-352, the system board side component height should be carefully
considered according to the datasheet of mPCIe connector selected.
