UNI-T UT107

C. DC Current
D. Resistance
E. Diode
55
Model UT107: OPERATING MANUAL
Range Resolution Accuracy
Overload
Protection
200mA
10A
0.1 mA
10 mA
(0.8%+5)
(1.2%+5)
Fuse 10A, 250V,
fast type,
5x20mm
Remark:
When measuring 5 to 10A:
For continuous measurement 10 seconds and interval
time between 2 measurement greater than 15 minutes.
l
Range Resolution Accuracy
Overload
Protection
200
2k
20k
200k
2M
20M
0.1
1
10
100
1k
10k
(0.8%+5)
(1.5%+5)
600Vp
Range Resolution
Overload
Protection
1mV
600Vp
Remark:
Open circuit voltage approximate 2.7V.
The silicon PN junction normal voltage is about 500
mV to 800 mV.
l
l
Fuse 315mA, 250V,
fast type,
5x20mm
