UNI-T UT201 User Manual

Rotary Switch
Below table indicated for information about the rotary switch
positions.
Rotary
Switch
Position
Function
AC/DC voltage measurement.
: Diode test.
: Resistance measurement.
Ω
Power is turned off.OFF
: Continuity test.
Ω
Temperature measurement
(UT202 only)
o
C
o
F
AC current measurement range from 0.001A
to 400.0A
A
Model UT201/202: OPERATING MANUAL
10

UNI-T UT201 Specifications

General

Data hold	Yes
AC current range	2 - 400 A
AC voltage range	2 - 600 V
DC voltage range	0.2 - 600 V
Basic accuracy (DC voltage)	±(0.8%+1)
Basic accuracy (resistance)	±(1%+2)
Dimensions (WxDxH)	75.6 x 30 x 210 mm
Battery voltage	3 V

Weight and Dimensions

Weight	220 g
