UNI-T UT201 User Manual

Measurement Operation(8)
F. Temperature Measurement (UT202 Only)
(see figure 8)
The temperature measurement ranges are -40
o
C~1000
o
C
and -40
o
F~1832
o
F.
To measure temperature, connect the Meter as follows:
1. Insert the red temperature probe into the VΩ
terminal and the black temperature probe into the COM
terminal.
2. Set the rotary switch to
o
F
o
C and press SELECT button
to select
o
F or
o
C measurement mode.
o
C measurement
mode is default.
3. Place the temperature probe to the object being measured.
The measured value shows on the display.
red black
( figure 8)
Note
l The Meter automatically displays the temperature
value inside the Meter when there is no temperature
probe connection.
l When temperature measurement has been completed,
disconnect the connection between the temperature
probe and the circuit under test, and remove the
temperature probe away from the input terminals of
the Meter.
Model UT201/202: OPERATING MANUAL
22

UNI-T UT201 Specifications

General

Data hold	Yes
AC current range	2 - 400 A
AC voltage range	2 - 600 V
DC voltage range	0.2 - 600 V
Basic accuracy (DC voltage)	±(0.8%+1)
Basic accuracy (resistance)	±(1%+2)
Dimensions (WxDxH)	75.6 x 30 x 210 mm
Battery voltage	3 V

Weight and Dimensions

Weight	220 g
