UNI-T UT201 User Manual

Display Symbols(1) (see figure 2)
No. Symbol Meaning
3
The battery is low.
Warning: To avoid false readings,
which could lead to possible electric
shock or personal injury, replace
the battery as soon as the battery
indicator appears.
4
The Meter is in the auto range mode
in which the Meter automatically selects
the range with the best resolution.
5
Test of diode.
6
The continuity buzzer is on.
7
Date hold is active.
8
1 AC Indicator for AC voltage or current
2 DC Indicator for DC voltage
MAX Maximum reading displayed
The unit of temperature:
o
C: Centigrade temperature
o
F: Fahrenheit temperature
o
C
o
F
9
Ω: Ohm. The unit of resistance.
kΩ: kilohm.1 x 10
3
or 1000 ohms.
MΩ: Megaohm. 1 x 10
6
or
1,000,000 ohms.
Ω,kΩ,MΩ
10
Model UT201/202: OPERATING MANUAL
13

UNI-T UT201 Specifications

General

Data hold	Yes
AC current range	2 - 400 A
AC voltage range	2 - 600 V
DC voltage range	0.2 - 600 V
Basic accuracy (DC voltage)	±(0.8%+1)
Basic accuracy (resistance)	±(1%+2)
Dimensions (WxDxH)	75.6 x 30 x 210 mm
Battery voltage	3 V

Weight and Dimensions

Weight	220 g
