UNI-T UT203 User Manual

Number Meaning
1
2
3
4
5
6
7
8
9
AC
DC
Symbol
Indicator for AC voltage or current
Indicator for DC voltage
The battery is low.
Warning: To avoid false readings, which could lead to
possible electric shock or personal injury, replace the
battery as soon as the battery indicator appears.
The Meter is in the auto range mode in which the Meter
automatically selects the range with the best resolution.
Test of diode
The continuity buzzer is on
Indicator for Duty.
Data hold is active
Indicator for REL mode
%
Model UT203/204: OPERATING MANUAL
16

UNI-T UT203 Specifications

General

Frequency range	0.01 - 1000 kHz
AC current range	40 - 400 A
AC voltage range	4 - 600 V
Continuity check	Yes
DC voltage range	0.4 - 600 V
Basic accuracy (frequency)	±(0.1%+3)
Basic accuracy (DC current)	±(2%+3)
Basic accuracy (DC voltage)	±(0.8%+1)
Basic accuracy (resistance)	±(1%+2)
Dimensions (WxDxH)	76 x 30 x 210 mm
Battery voltage	9 V

Weight and Dimensions

Weight	200 g
