UNI-T UT203 User Manual

E. Continuity Test
Range Resolution Accuracy Overload protection
100m
Around 50 ,
the buzzer beeps
600Vp
Remark:
Open circuit voltage approximate 0.45V.
The buzzer may or may not beeps when the resistance of a circuit under test is
between 50 ~100
The buzzer will not beep when the resistance of a circuit under test is > 100 .
l
l
l
Model UT203/204: OPERATING MANUAL
38

UNI-T UT203 Specifications

General

Frequency range	0.01 - 1000 kHz
AC current range	40 - 400 A
AC voltage range	4 - 600 V
Continuity check	Yes
DC voltage range	0.4 - 600 V
Basic accuracy (frequency)	±(0.1%+3)
Basic accuracy (DC current)	±(2%+3)
Basic accuracy (DC voltage)	±(0.8%+1)
Basic accuracy (resistance)	±(1%+2)
Dimensions (WxDxH)	76 x 30 x 210 mm
Battery voltage	9 V

Weight and Dimensions

Weight	200 g
