UNI-T UT203 User Manual

Battery Life: typically 150hours (alkaline battery)
Sleep Mode (can be disabled)
Dimensions (H x W x L): 208mm x 76mm x 30mm.
Weight: Approximate 260g (battery included)
l
l
l
l
B. Environmental Requirements
The Meter is suitable for indoor use.
Altitude: Operating: 2000m
Storage: 10000m
Safety/ Compliances: IEC 61010 CAT.II 600V, CAT.III 300V over voltage and
double insulation standard.
Temperature and humidity:
Operating: 0ºC~30ºC ( 85%R.H);
30ºC~40ºC ( 75%R.H);
40ºC~50ºC ( 45%R.H);
Storage: -20ºC~+60ºC ( 85%R.H)
l
l
l
l
Model UT203/204: OPERATING MANUAL
34

UNI-T UT203 Specifications

General

Frequency range	0.01 - 1000 kHz
AC current range	40 - 400 A
AC voltage range	4 - 600 V
Continuity check	Yes
DC voltage range	0.4 - 600 V
Basic accuracy (frequency)	±(0.1%+3)
Basic accuracy (DC current)	±(2%+3)
Basic accuracy (DC voltage)	±(0.8%+1)
Basic accuracy (resistance)	±(1%+2)
Dimensions (WxDxH)	76 x 30 x 210 mm
Battery voltage	9 V

Weight and Dimensions

Weight	200 g
