UNI-T UT208 User Manual

The DC Voltage ranges are: 6.6V, 66V and 600V
The AC Voltage ranges are: 6.6V, 66V and 600V
To measure DC/AC voltages, connect the Meter as follows:
Insert the red test lead into the V Hz terminal and black test lead into the COM
terminal.
Set the rotary switch to V . DC mesaurement mode and auto ranging is a
default. Press SELECT to switch to AC measurement mode.
Press Hz button to measure frequency or duty cycle, but the frequency or duty
cycle readings obtained from this range is only for reference.
Connect the test leads across with the object being measured.
The measured value shows on the display.
1.
2.
3.
4.
Note
When DC/AC voltage measurement has been completed, disconnect the connection
between the testing leads and the circuit under test and remove testing leads
from the input terminals.
Model UT207/208: OPERATING MANUAL
19
