UNI-T UT208 User Manual

Insert the red test lead into the V Hz terminal and black test lead into the COM
terminal.
Set the rotary switch to
. Press SELECT to switch to measurement
mode.
For forward voltage drop readings on any semiconductor component, place the
red test lead on the component’s anode and place the black test lead on the
component’s cathode.
1.
2.
3.
Note
To obtain a more precise reading, you could remove the objects being tested from
the circuit when measuring.
When diode testing has been completed, disconnect the connection between the
testing leads and the circuit under test and remove testing leads from the input
terminals.
Model UT207/208: OPERATING MANUAL
23

UNI-T UT208 Specifications

General

Brand	UNI-T
Model	UT208
Category	Multimeter
Language	English
