UNI-T UTD2052CL+ - Bit Map Storage and Load; Screen Copy

UTD2000 Series User Manual
45
Storage
Press the button to store.
9.3 Bit map storage and load
Press the Storage button, then press F1 to choose storege type Data File, and you
will see the following menu.
Table 9-6 Interface storage menu
Function Menu
Setting
Description
Type
Data file
The selected storage type is data file, stored in CSV format.
Storage medium
USB
Only when the USB is plugged into DSO can the data file be stored.
File name
Customized
Please refer section 9.1 “Edit file name”.
Save
Press the button to save.
Note: Only when the USB is plugged into DSO can the data file be stored.
9.4 Screen copy
Press PrtSc button, then current screen will be stored in USB in BMP format. This bitmap
can be viewed on PC. Only when the USB is plugged into DSO can the bitmap be stored.
