Unic Rumba User Manual

N L1 PE L3 L2
N1 L1 L2 L3
N0 1 2 3
ON / OFF
SWITCH
BORNIER
ENTRELEC
PLUG
PRESSOSTAT
PRESSURESTAT
RESISTANCE
HEATING ELEMENT
N 1 2 3
1
4
2
6
3
5
4 5 6
4 5 6
THERMOSTAT DE SECURITE
RESISTANCE
HEATING ELEMENT SAFETY
THERMOSTAT
121212
EV VAPEUR
STEAM EV
EV VAPEUR
STEAM EV
EV EAU
WATER EV
BP VAPEUR
STEAM SWITCH
BP VAPEUR
STEAM SWITCH
BP EAU
WATER SWITCH
M POMPE
PUMP MOTOR
EV CAFE 2
COFFEE EV
EV CAFE 1
COFFEE EV
EV CAFE 3
COFFEE EV
EV REMPLISSAGE
FILLING EV
DOSEUR EAU
WATER DOSER
Fu
COMPTAGE
11 10 9 7 6 5 4 3 2
35 34 33 32 31 30 29 28 27 26 25 24 23 22 21
RPCNPh
Fu
COMPTAGE
11 10 9 7 6 5 4 3 2
35 34 33 32 31 30 29 28 27 26 25 24 23 22 21
RPCNPh
Fu
COMPTAGE
11 10 9 7 6 5 4 3 2
35 34 33 32 31 30 29 28 27 26 25 24 23 22 21
RPCNPh
1
2/3/4
5
6
N 1 2 3
1 2 3
P1 P2 P3
CHAUDIERE VAPEUR
STEAM BOILER
BOITIER ELECTRONIQUE1
ELECTRONIC BOX
123
06/09/03
SCHEMA DE CABLAGE
TRI RUMBA
WIRING DIAGRAM
380-400-415 V Tri 50/60HZ+N+TERRE
