1. PREPARATION OF THE SITE
The machine is delivered in a cardboard box screwed onto a wooden pallet.
A. Unpack the machine
- Cut the tightening strap with shears.
- Open the cardboard box and take the accessories’ container out.
- Make screws loose by slightly inclining the cardboard box.
- Take the machine out of the cardboard box and put it on wooden blocks.
- Remove screws and washers used for transport.
B. Install the machine and preparation of the site
- Put the machine in its final place and level it up with the help of rubber washers, as necessary.
- The machine must be placed on a horizontal surface.
- There must be a free space of 5 cm behind the machine and the ventilation holes on the top of the machine
must not be obstructed.
- A socket with a ground system and a water-supply pipe corresponding to the characteristics of the machine
are sufficient for connecting.
Set up cup racks after making adjustments.
2. HYDRAULIC CONNECTION
A water softener is necessary.
Water Intake
- Pressure ranging from 0 to 10 bar
- Connection : 3/8 gas female socket (male plug on
machine)
- Pipe with a minimum 8 mm internal diameter
- Stop valve to be set up.
Drainage
- Connection : 3/4 gas female socket (male plug on
machine)
- Pipe with a minimum 12 mm internal diameter.
