SEAT BELT
WARNING
Be sure to fasten the seat belt before starting
the truck; otherwise, if the truck turns over, the
operator might be thrown out and, in the worst
case, the operator can be crushed by the truck.
Pull out the connector and insert it into the receptacle
until it clicks into place.
To unfasten the seat belt, press the red button by the
receptacle, and the belt will automatically wind up into
the seat.
GLOVE BOX
The glove box is located under the dashboard
diagonally to the left in front of the operator’s seat. The
glove box can be detached and is portable.
4
3
2
SEAT BELT
CONNECTOR
RECEPTACLE
GLOVE BOX
2-16
INSTRUMENTS AND CONTROLS
