Thanks for purchasing RH144 4 x 4 MultiView HDMI Matrix. With our highly reliable and quality product,
you can enjoy countless benefits by using this device.
Introduction
RH144, 4 x 4 MultiView HDMI Matrix is the only complete independent HDMI system that arrange four
HDMI multimedia sources and dynamically exhibit them on 4 displays in various mode. Each source can
be independently scale. Switching do not have delays or black screen. It is the ideal solution for A/V
Switching, Splitting, or Broadcasting.
Features
■
Complete independent video wall system with 6 video mode selection with 8 video configuration
programmable memory.
■
Dynamically and smooth scaling of up to 4 inputs
■
Select any of the input to be display up to 4 monitors
■
Change mode and scaling with no delays
■
Intuitive mode operation by front panel Push Buttons, OSD, or IR Remote Control
■
Full HD Digital Video resolution can support up to 1920 x 1200 to give a combine total of 4K x 2K video
resolution
■
Support Locking HDMI cables
■
Sturdy metal rack-mountable casing designed for 1U application
■
Optional IR remote control Unit accessories or Ethernet access available
Specification
Model No. RH144
Video In 4 x HDMI Type A Female (Lockable)
Video Out 4 x HDMI Type A Female (Lockable)
RS232 1 x DB9, Female
IR 1 x Receiver and 1 x IR Extender (3.5mm Earphone Jack)
LEDs 16 fixed + 24 switch
Switch/Button 24 x Momentary Switch
1 x Power Switch
Video Resolution Full HD or 1920 x 1200
Operation Temperature 0 ~ 40
℃
Storage Temperature -20 ~ 60
℃
Humidity 0~90% RH, Non-condensing
Weight 2.1 Kg
Dimension(L x W x H) 437 x 205 x 43 mm
Housing Metal enclosure
Power Adapter DC 12V
Safety / Emission FCC, CE
Package contents
■
RH144 unit x1
■
Power adapter x1
■
User manual x1
■
IR extender x1
■
RS-232 cable x1
■
Remote control x1
