Uniclass RH144 - Keyboard Hotkeys

7
3. Keyboard hotkeys
Command Hotkeys Description
Menu/Select Enter
■
Press to bring up the OSD menu.
■
Select a desired option on the menu.
Up/Down/Left/Right
/ /
/
(Cursor buttons)
Press to move the cursor up, down, left and right on the menu.
Exit Esc Press to exit the OSD menu.
Mode selection F1~F6 Press to switch a preferred mode.
F1: Matrix F2: PIP F3: Windows
F4: Video Wall F5: PAP F6: Quadview
Matrix 1~4, A~D Press to switch to Matrix mode. The hotkey of Matrix mode is
consisted with 2 keystrokes. For example, to monitor source 2
on display B, you can press 2 and then press B.
PIP 1~4/ALT
■
Press to switch between different source on the main display.
■
To switch between different subordinate display, press
ALT+1~4.
Windows 1~4/ALT
■
Press to display the source on top layer.
■
To turn on/off the source display, press ALT+1~4.
Video wall 1~4 Select the desired source.
PAP 1~4 Select the source to playback on the main display.
Quadview 1~4 Select the desired source.
