Unilumin Upanel 1.2S User Manual

Chapter 2 Installation and Wiring
8
3) Install part of the vertical back frames without tightening the screws. Install 2*2
cabinets from the bottom and adjust the vertical back frames. Then tighten the
screws on the vertical back frames. Install other vertical back frames in a similar
way.
Fig 2-4 Installation Diagram 3
Figure 2-5 Taper Screw Figure 2-6 Vertical Back Frame
Figure 2-7 Aluminium Profile Figure 2-8 Embedded Plate and Corner Bracket
Embedded Plate and
Corner Bracket
Taper Screw
Vertical Back Frame
Aluminium Profile
