UniPOS Fire Control Panel FS5200
Instruction manual Page 11
Revision 8/07.17 of 69
4.10. Dimensions
 dimensions - 450х355х115mm
4.11. Weight
 Backup batteries not included - 6,6kg
5. Contents of delivery
5.1. Fire control panel
 Fire control panel FS5200 - 1 pc
 Resistors 3,9k/ 0,25W - 8 pcs
 Resistors 5,6k/ 0,25W - 1 pc
 Jumper for the backup batteries - 1 pc
 Fuse 4A - 2 pcs
 Instruction manual - 1 pc
 Instruction for the authorized staff - 1 pc
 Packing - 1 pc
5.2. Additional module
 Additional module - 1 pc
 Ribbon cable - 1 pc
 Earthing cable - 1 pc
 Resistors 3,9k/ 0,25W - 8 pcs
 Resistor 5,6k/ 0,25W - 1 pc
 Special nut - 1 pc
 Packing - 1 pc
5.3. Module 5201
 Module 5201 - 1 pc
 Resistors 3,9k/ 0,25W - 8 pcs
 Screw М3 - 2 pcs
 Plain washer М3 - 2 pcs
 Spring lock washer М3 - 2 pcs
 Packing - 1 pc
5.4. Module 5203 or 5204
 Module 5203 or 5204 - 1 pc
 Screw М3 - 2 pcs
 Plain washer М3 - 2 pcs
 Spring lock washer М3 - 2 pcs
 Packing - 1 pc
6. General information
6.1. Access levels
There are 4 levels of access to the variable indications and control functions of FS5200.
6.1.1. Access level 1
All persons who would presumably find out and react to alarm for fault condition or fire condition
have access to level 1.
The following features are accessible:
 Displaying suppressed messages for Fire condition, Pre-fire condition, Fault condition
and Disabled components (see sections 8, 9, 10 and 11);
 Entering inspection time period (see section 8);
 Forced proceeding from phase Fire condition stage I to phase Fire condition stage II (see
section 8);
 Suppressing the local sounder (see sections 8, 9 and 10);
 Displaying the status of the lines and of the controllable outputs (see section 13).
All light indicators are visible.
