UniPOS FS5200 User Manual

UniPOS Fire Control Panel FS5200
Instruction manual Page 17
Revision 8/07.17 of 69
If there are more than two lines in Fire condition, the rest of the text messages are suppressed.
They can be displayed in the first field by the means of the keypad (see section 8.3.5).
8.3. Using the keypad
8.3.1. Button (Inspection)
When you press the Inspection button, the time period, already programmed by the user, will be
added to the remaining time for all lines in Fire condition stage I before they proceed to Fire condition
stage II.
The button is active when a fire alarm line enters Fire condition stage I.
8.3.2. Button (Alarm)
Press it to:
 Switch off the local sounder if it responded to Fire condition/Pre-fire condition or Fault
condition;
 Activate the local sounder if the control panel I in Fire condition, Pre-fire condition or Fault
condition and the sounder has been suppressed by previous pressing of the same button.
The LED indicator on the button illuminates if the sounder has been switched off after response to
Fire condition, Pre-fire condition or Fault condition.
The button does not affect and is not cancelled by the following events:
 When a new line enters Fire condition or proceeds from Fire condition stage I to Fire condition
stage II, the local sounder will be activated due to Fire condition/Pre-Fire condition;
 When a new line enters Pre-Fire condition the local sounder will be activated for Fire
condition/Pre-Fire condition only;
 A new Fault condition will trigger the local sounder for Fault condition only.
The LED indicator of the button stays illuminated, if the signalizations and/or the outputs remain off.
The button is active at Access levels 1 and 2.
8.3.3. Button (Outputs)
The button operation depends on the current access level and on the status of the fire control
panel.
At Access level 1 (the key on the front panel is in position ) and some fire alarm lines are in
phase Fire condition stage I, the button will trigger forced proceeding to phase Fire condition stage II
in effect for these particular lines.
At Access level 2 (the key on the front panel is in position ) and some fire alarm lines are in
phase Fire condition stage I, the button has the following operations:
 If no activated outputs for fire condition are available – the button will trigger forced proceeding
to Fire condition stage II effective to these lines;
 If activated outputs for fire condition are available – the button will suppress the outputs.
At Access level 2 (the key on the front panel is in position ) and no fire alarm lines are in
Fire condition stage I (i.e. the fire control panel is in phase Fire condition stage II) the button has the
following operations:
 If activated outputs for fire condition are available - the button will suppress the outputs;
 If no activated outputs for fire condition are available – the button will activate the suppressed
outputs, if any.
The LED indicator on the button illuminates if some outputs for fire condition are suppressed.
8.3.4. Button (Reset of line)
It forces the fire control panel to exit Fire condition in the fire alarm line, indicated in the first line of
the LCD display, and resets the line (cuts off the power supply for 3 seconds).
The button is active at Access level 2 (the key on the front panel is in position ).
