UniPOS Fire Control Panel FS5200
Instruction manual Page 16
Revision 8/07.17 of 69
stage II. The time period for Fire condition stage I is limited and is user programmable, separately for
each line (up to 255 seconds). The period can be prolonged with the Inspection time (see section
8.3.1). When Fire condition stage I in one line expires, the fire control panel enters Fire condition
stage II in the same line.
The fire control panel enters Fire condition stage I upon activation of an automatic fire detector
when the current value in the line is between the limits for Fire condition stage I and Fire condition
stage II. The fire control panel enters Fire condition stage II upon activation of a manual call point
when the current in the line is between the limits for Fire condition stage I and Short circuit. All
threshold values are user defined, separately for each line (see sections 14 and 14.3.1). Night Mode
phase Fire condition stage I is ignored. The fire control panel enters Fire condition, phase Fire
condition stage II:
upon activation of an automatic fire detector when the current value in the line is between the
limits for Fire condition stage I and Fire condition stage II, and
upon activation of a manual call point when the current in the line is between the limits for Fire
condition stage I and Short circuit.
The fire control panel can be in Fire Condition in one or more lines. When the fire control panel is
in Day Mode, it can register Fire condition stage I in part of the lines, and Fire condition stage II in the
rest of the lines.
To exit this condition press button at Access level 2 (see section. 8.3.4) for each fire alarm
line in fire condition. If a System fault occurs the operation of Fire condition will suffer changes (see
section 10.1).
8.2. Indication
8.2.1. LED and sound indication
In this condition the common light indicator (Fire condition stage I) and/or (Fire
condition stage II) flash in red.
If the outputs for fire condition are suppressed by button (Outputs), the LED indicator on
the button will illuminate in red.
If Inspection time has been entered, the indicator illuminates in continuous green light
(Inspection).
The local sounder produces continuous signal. If the sound indication has been suppressed by
button (Alarm), the LED indicator on the button illuminates in continuous red light.
8.2.2. Text message
Information for all lines in Fire condition appears on the display:
The display is divided into two text fields each containing two lines. Information on the first line in
Fire condition is visualized in the first (top) field; information on the last line in Fire condition in the
second (bottom) field.
The first line of each field displays information on the type of the Fire condition:
N1 is the consecutive number of the Fire condition, indicated in the first field;
N2 is the consecutive number of the Fire condition, indicated in the second field (in our case,
this is the last fire condition, so N2 is the total number of fires);
Fire1 / Fire2 is the phase of the Fire condition registered for this line;
NN is the line number
SSS is the remaining time in seconds, before the fire control panel proceeds to Fire condition
stage II (it is indicated only in Fire condition stage I).
The second line of each field displays a text message for the corresponding fire alarm line.
N1 Fire 1 LnNN SSSs
Message 1
N2 Fire 2 LnNN
Message 2
