Page #6 background image
UniPOS Fire Control Panel FS5200
Instruction manual Page 6
Revision 8/07.17 of 69
FIRE CONDITION STAGE I upon activation of automatic fire detector the fire control panel
enters Fire condition, phase Fire condition stage I until the defined time expires. The common and
local light indicators, local sound signaling and a text message displayed on the LCD display indicate
the phase.
FIRE CONDITION STAGE II the fire control panel enters Fire condition, phase Fire condition
stage II when: a) the time for Fire condition stage I has expired or b) upon activation of a manual call
point. The common and local light indicators, local sound signaling and a text message displayed on
the LCD display indicate the phase.
FUNCTION “LOGICAL AND” OF TWO LINES function that allows the fire control panel to enter
Fire condition stage I in two lines upon simultaneous activation of automatic fire detectors (see
section 6.3)
GROUNDS non-system non-fatal fault condition, due to leakage to a grounded wire.
GROUP ADDRESSING fire control panel’s ability to make a difference between activation of
automatic fire detector and manual call point, which are in one and the same fire alarm line. For this
purpose the manual call points’ current consumption value shall exceed the threshold value for Fire
condition stage II.
INSPECTION TIME period of time added to the remaining time, before the system proceeds
from Fire condition stage I to Fire condition stage II, when button is pressed. Usually, this
period of time is long enough for the authorized personnel to check up the indicated premises. The
inspection time is user defined and is equal for all fire alarm lines. Light indicators show adding a
period of time for inspection.
INTERRUPTED LINE OR CONTROLLABLE OUTPUT non-system non-fatal fault condition due
to current value in a line or in a controllable output lower than the threshold value. The user shall
define the threshold value separately for each line.
LINE IN TEST line set by the user to Test condition. The line is powered and reset (the power is
cut off for 3 s) periodically every 64 s. The events registered in a line in Test condition are not saved
in the archive and do not trigger the associated outputs nor the light and sound signaling. The
indication for a line in Test condition is common light indication.
LINE STATUS OR CONTROLLABLE OUTPUT STATUS current status of a line or a
controllable output: normal status; fire conditions stage I or II (for a line only); fault condition and its
type.
LOCAL SOUNDER - sounder built-in the fire control panel.
LOW BATTERY non-system fatal fault condition due to full discharge of the backup batteries
upon interrupted power supply.
NEW CONFIGURATION a system fatal fault condition due to detected conflict between the
current physical configuration and the configuration saved in the memory. Usually it occurs when a
module has been added, removed or replaced. In such case adjust the settings in the fire control
panel.
NON-FATAL FAULT CONDITION fault condition that allows the fire control panel to continue
operation. A non-fatal fault condition is usually a non-system fault condition. The indication is common
light indication, local sound indication and text messages on the LCD display.
PRE-FIRE CONDITION condition of the fire control panel used by the function Logical AND of
two lines to provide control over simultaneous response of automatic fire detectors in the lines. (see
section 6.3 )
