UNIRAC EcoFoot2+ - Mechanical Load Test; Mechanical Load Test Modules and Ratings

PAGE SYSTEM CERTIFICATION
24
10-DEGREE BALLASTED RACKING SYSTEM
The EcoFoot2+
TM
system has been certied and listed to the UL 2703 standard (Rack Mounting Systems and Clamping Devices for Flat-Plate Photovoltaic Modules
and Panels). This standard includes electrical grounding, electrical bonding, mechanical load and re resistance testing.
In conducting these tests, specic modules are selected for their physical properties so that the certications can be broadly applied. The following lists the specic
modules that were tested and the applicability of those certications to other modules that might come onto the market. PV modules may have a reduced mechani-
cal load rating, independent of the EcoFoot2+
TM
load rating. Please consult the PV module manufacturer's installation guide for more information.
In addition to UL 2703 certication, Unirac performs internal testing beyond the requirements of certication tests in order to establish system functional limits,
allowable loads, and factors of safety. These tests include functional system tests, and destructive load testing.
MECHANICAL LOAD TEST
Module Manufacturer Model / Series Area [sq ft]
Design Load without Mid Supports
[psf]
Design Load down with Mid Sup-
ports [psf]
Boviet Solar
BVM6612 M 20.89 11.8 up / 30 down 50
Canadian Solar
CS6P-XXXM 17.31 30 up / 30 down N/A
CS6X-XXXP 20.65 15 up / 38 down 50
CS6U-XXXM 20.93 13.3 up / 25 down 50
CS3W-MB-AG 24.05 13.87 up / 13.8 down 40.55
CS3U-MB-AG 21.59 13.33 up / N/A down 40
ET Solar ET-M672XXXWW 20.86 15 up / 20 down 40
Hansol HSXXXTD-AN4 21.46 15 up / 20 down 35
Heliene 72M-XXX 20.89 15 up / 25 down 34
Hyundai
HiS-MXXXTI 21.06 10.2 up / 30 down 40
HiS-MXXXRI 21.06 15 up / 20 down 33.3
MECHANICAL LOAD TEST MODULES
The modules selected for UL 2703 mechanical load testing were selected to represent the broadest range possible for modules on the market.
The tests performed cover the following basic module parameters:
• Frame thicknesses greater than or equal to 1.0 mm.
• Basic single and double wall frame proles (some complex frame proles could require further analysis to determine applicability).
• Clear and dark anodized aluminum frames.
• All installation congurations have achieved a minimum of 5psf design load in the downslope direction, tested with the Q Cells Q.PEAK DUO
XL-G11.3/BFG module listed in this table
