PAGE SYSTEM CERTIFICATION
26
10-DEGREE BALLASTED RACKING SYSTEM
Module Manufacturer Model / Series Area [sq ft]
Design Load without Mid Supports
[psf]
Design Load down with Mid Sup-
ports [psf]
Trina
TSM-XXX PA05.08 17.64 30 up / 30 down N/A
TSM-XXXDE14A(II) 20.93 15 up / 30 down 40
DE18M(II) 25.94 18.92 up / 19.01 down 37.85
VSUN VSUNXXX-72MH 21.38 13.33 up / 20 down 50
Yingli YGE 60 17.58 30 up / 30 down N/A
ZN Shine ZXM6-72 21.4 13.33 up / 16.27 down 40
MECHANICAL LOAD TEST
